CONNECTION OF SEPARATE SYSTEMS
3
19
OPTISONIC 7300 / 8300
www.krohne.com
05/2012 - 7312262200 - AD EX OPTISONIC 7300/8300 R02
Figure 3-2: Clamp the cables on the shielding bush.
1 Cables.
2 Cable glands.
3 Grounding clamps.
4 Cable with metal shielding bush.
Figure 3-3: Connect the cables on the signal converter.
