RKW 600W 060110
3
Isolation: (at 15-35°C ambient, 10-
85% relative humidity)
Between input and case
2000Va-c for 1 minute. Cutout current is 20mA
Between output and case
500Va-c for 1 minute. Cutout current is 100mA
Between input and output terminal
2000Va-c for 1 minute. Cutout current is 20mA
Insulation Resistance: (at 15-35°C
ambient, 10-85% relative humidity)
Between output and case, input and case, and input and output, 100 Megohms minimum
(500Vdc)
Humidity:
10% to 95% relative humidity, noncondensing, Wet Bulb temper-
ature<35°C
operating and non-operating
Vibration:
5-10 Hz., 10mm amplitude, 10-200 Hz.,
acceleration 64.3ft./s
2
(19.6m/s
2
) (2g)
non-operating, 1 hr. on each
of 3 axes, Power Supply is
fixed on its bottom side)
Shock:
(non-operating, 1/2 sine pulse,
three shocks on each axis, Power
Supply is fixed on its bottom side)
964.6ft./s
2
(294m/s
2
) (30g), 11ms ± 5 msec pulse duration
Safety:
All units designed to meet UL1950, CSA Electrical Bulletin 22.2 No.950-95 (certified by UL),
and TÜV Rheinland EN60950 (ambient temp. 50°C max.). Meets Creepage and Clearance
requirements of Dentori, Appendix 8. RKW 600W units are CE marked per the Low Voltage
Directive (LVD), 73/23/EEC and 93/68/EEC. [The standards do not apply with DC input opera-
tion]
EMI Conducted:
Designed to meet: FCC Class B, VCCI-Class B, EN55011-B, EN55022-B.
EMI radiated:
Designed to meet: FCC Class B, VCCI-Class B, EN55011-B, EN55022-B.
Input current harmonics:
Designed to meet: EN61000-3-2.
ESD immunity:
Designed to meet: EN61000-4-2, level 4.
normal operation
Fast transient burst immunity:
Designed to meet: EN61000-4-4 level 3.
normal operation
Surge immunity:
Designed to meet: EN61000-4-5, level 4.
no damage
Power frequency magnetic field
immunity:
Designed to meet: EN61000-4-8, level 4.
normal operation
Radiated field immunity:
Designed to meet: EN61000-4-3 level 3.
normal operation
Conducted noise immunity:
Designed to meet: EN61000-4-6 level 3.
normal operation
Voltage dips interruptions and
variations:
EN61000-4-11
normal operation
Dimensions:
3.62 in. (92 mm) x 4.72 in. (120 mm) x 7.87 in. (200 mm)
Mounting:
No. M4 tapped holes
Maximum Screw Penetration:
0.24 in. (6 mm)
Cooling:
Forced air flow - one fan
Frame Material/Cover Material:
Steel
Weight:
5.95 lbs. (2.7 Kg) typical, 6.61 lbs. (3.0 Kg) maximum
TABLE 2. POWER SUPPLY RATINGS AND SPECIFICATIONS (CONTINUED)
SPECIFICATION
DESCRIPTION
