Page 8
8
RA75/RA76 6/20/03
RA 75, RA 76
CHASSIS ASSEMBLY
CODE: 1306153
REFERENCE
DESIGNATOR
QTY.
DESCRIPTION
MFRS. NAME & PART NO.
(SEE BOTTOM NOTE)
KEPCO
PART NO.
REC. SPARE
PART QTY.
NOTE: REPLACEMENT PARTS MAY BE ORDERED FROM KEPCO, INC. ORDERS SHOULD INCLUDE KEPCO PART NUMBER AND DESCRIPTION.
PLEASE NOTE: THE MANUFACTURER'S NAME AND PART NUMBER LISTED FOR EACH ITEM ON REPLACEMENT PARTS LISTS REPRESENTS
AT LEAST ONE SOURCE FOR THAT ITEM AND IS LISTED SOLELY FOR THE CONVENIENCE OF KEPCO EQUIPMENT OWNERS IN OBTAINING
REPLACEMENT PARTS LOCALLY. WE RESERVE THE RIGHT TO USE EQUIVALENT ITEMS FROM ALTERNATE SOURCES. KEPCO, INC.
KEPCO
REPLACEMENT PARTS LIST
A1J1, A1J2
2
ASSY., PLUG, PCB MOUNT
(STRAIGHT PINS), 4 PINS
AMP INC
640445-4
142-0282
1
CB1
1
CIRCUIT BREAKER, (FULLY MAG-
NETIC), 1POLE 125VAC 7.5A
CARLING TECHNOL
MF1-B-34-475-1-BB2-B-C
127-0383
1
DS1, DS2, DS3
3
DEVICE, SIGNALING, , LED-GN
DIFFUSED LENS, VF=2.7V
DIALIGHT CORP.
521-9250
153-0094
1
J1
1
CONNECTOR, POWER INLET,
3 PINS
SCHURTER
6100-4115
143-0616
1
P1, P2
2
PLUG, SOCKET, CABLE CONNEC-
TOR, 4 PINS
AMP INC.
640428-4
143-0339
1
RS1
1
RES., FIX., CARBON FILM,
33 KOHM , 1/2W, 5%
KOA/SPEER
CF1/2 333 J T52A
115-1127
1
TB1
1
TERMINAL BLOCK,
15 TERMINALS, 20A/TERM.
MAGNUM (USD)
A2193-15-07-MP
167-1023
1
TB2
1
TERMINAL BLOCK, COMPACT,
12 POLE
WIELAND
29.401.1253 *
167-0995
1
TB3
1
TERMINAL STRIP, 4 LUGS
KEYSTONE ELECTR
818
167-0554
1
TP1(+), TP2(+),
TP3(+)
3
TEST POINT, JACK-RED
KEYSTONE ELECTR
6025
173-0001
1
TP1(-), TP2(-),
TP3(-)
3
TEST POINT, JACK-BK
KEYSTONE ELECTR
6026
173-0002
1
