KEPCO Kit 219-0439, 219-0440, 219-0441, ATE-DMG External Control Kit - Manual

©2005, KEPCO, INC 1
Data subject to change without notice 228-1469 REV 3
I N S T R U C T I O N M A N U A L
ATE-DMG
KEPCO
KEPCO, INC. G 131-38 SANFORD AVENUE G FLUSHING, NY. 11352 U.S.A. G TEL (718) 461-7000 G FAX (718) 767-1102
http://www.kepcopower.com G email: [email protected]
An ISO 9001 Company.
EXT. CONTROL
KIT
ATE-DMG
EXTERNAL CONTROL
FIELD UPGRADE KITS
219-0439, 219-0440, 219-0441, 219-0463
1. DESCRIPTION
Kepco Kits 219-0439 for ATE 36-30DMG, 219-0440 for ATE 100-10DMG, 219-0441 for ATE 25-40DMG and 219-0463 for ATE 75-
15DMG allows these models to be upgraded to accommodate external control of the output. Each kit contains a specially modified
PC-12 connector (adapter assembly A11) with associated interconnect cable and a PROM which upgrades the firmware.
2. INSTALLATION OF COMPONENTS
2.1 MATERIAL REQUIRED (SEE TABLE 1.)
2.2 DISASSEMBLY PROCEDURE
1. Turn power off, disconnect the unit from source power and remove line cord.
2. Remove the top cover of the unit by removing 20 screws as follows: two at top of the rear panel and nine on each side.
2.3 PROM REPLACEMENT PROCEDURE (SEE FIGURE 1)
NOTE: The PROM included in this Kit updates the firmware to Rev 6.3. If the firmware is already at Rev 6.3 or later, it is not
necessary to replace the PROM. Skip to PAR. 2.4 for Adapter Assembly replacement. Verify the PROM revision by
pressing the MENU Key on the ATE-DMG keypad until the display shows the operating configuration. (See PAR. 2.8 of
the ATE-DMG Technical Manual.)
1. Locate PROM, U16 on Digital board A7 (see Figure 1).
2. Take the wrist strap from kit and use the peel and stick area to connect the wrist strap to the chassis of the ATE-DMG.
Place the wrist strap on your arm as indicated by the instructions for the wrist strap.
3. Touch the IC tube to the chassis of the ATE-DMG. Open one end.
4. Pry out the PROM using an IC extractor. Insert the hook, first into one slot and then the other, and gently pry out the PROM.
Place the PROM in the tube and close the tube.
5. Open the other end of the IC tube and remove the replacement PROM from the tube.
6. Insert the PROM into the socket, ensuring the dot is oriented as shown in Figure 1.
TABLE 1. MATERIAL REQUIRED
MATERIAL PART NUMBER LOCATION QUANTITY
• PROM Replaces U16 in Board A7 Different with each kit Provided in this Kit 1
• Adapter assembly A11 with Interconnect cable. Different with each kit Provided in this Kit 1
• Instruction Manual KEPCO P/N 228-1469 Provided in this Kit 1
• ESD (Electrostatic Discharge) wrist strap (KEPCO P/N 114-0080) KEPCO P/N 114-0080 Provided in this Kit 1
• IC Extractor 114-0079 Provided in this Kit 1
• Phillips Screw Driver N/A Not Supplied N/A
