III — SPECIFICATIONS (STANDARD)
The following specifications apply to all standard (no suf-
fix) HSF-PFC 100 Watt Series models. Table 1 lists the
specifications that differ for each model. Common specifi-
cations that apply to all standard models are listed in the
paragraphs following Table 1. Other models are also avail- able; consult your Kepco representative for their specifica-
tions.
NOTE: Common specifications apply to all models except
where otherwise indicated.
INPUT:
Voltage:
Nominal:120V a-c/240V a-c;
Range:
90-264V a-c;
125-370V d-c. (polarity insensitive)
Frequency: Nominal: 50-60 Hz; Range: 47-440Hz
(From 66 to 440 Hz leakage current may exceed
UL/VDE safety spec. limit.)
Current (nominal output at rated load):
1.4A a-c max @120V a-c rms
1.2A max for 3.3V model
0.7A a-c max @240V a-c rms
0.6A max for 3.3V model
Initial Turn-on Surge: cold start 25°C (First surge
only, not including the current flow into the EMI fil-
ter):
14A typ. @ 100 V a-c, 100% load
28A typ. @ 200 Va-c, 100% load
Power Factor: 0.99 typ. @100V a-c;
0.95 typ. @ 200V a-c.
Switching Frequency:
135KHz typical
STABILIZATION:
Source Effect (full load): 0.2% typ.; 0.3% max.
Range 90-132V a-c, 170 -264V a-c,
Load Effect (10% to 100% load change):
0.5% typ.; 1.5% max.
Temperature Effect: Range –10
o
to 71
o
C
0.5% typ.; 1.0% max.
Combined Effect (includes source, load, and
temperature effects):
0.9% typ.; 1.8% max.
Time Effect (1/2 hr-8 hr at 25 o C):
0.2% typ.; 0.5% max.
RECOVERY CHARACTERISTICS: A step load
change from 50% to 100% produces less than +4% output
excursion. Recovery occurs to within +1% of the original
setting in <1 ms (load change t
r
or t
f
equal to or greater
than 50 µsec).
START-UP TIME:
500 ms. maximum @100V a-c
300 ms. typical @100V a-c
200 ms. maximum @240V a-c
100 ms. typical @240V a-c
TABLE 1. OUTPUT RATINGS AND SPECIFICATIONS, HSF-PFC 100W SERIES (STANDARD: NO SUFFIX)
MODEL
HSF
3.3-20PFC
HSF
5-20PFC
HSF
12-8.5PFC
HSF
15-7PFC
HSF
24-4.5PFC
HSF
28-3.8PFC
HSF
48-2.1PFC
OUTPUT VOLTS, d-c (NOMINAL) 3.3V 5V 12V 15V 24V 28V 48V
ADJUSTMENT RANGE 2.8 - 3.4V 4.3 - 5.3V 11.4 - 12.6V 13.5 - 16.5V 19.2 - 26.0V 26.5 - 29.5V 44.0 - 52.0
OVERVOLTAGE SETTING
(25 °C, NOM. INPUT)
3.4 - 4.6V 5.2 - 6.0V 13.2 - 15.2V 16.5 - 18.5V 26.5 - 30.0V 31.5 - 34.5 53.0 - 59.5
OUTPUT CURRENT (NOMINAL)
(1)
20A 20A 8.5A 7.0A
4.5A
(6.5A Peak)
(4) 3.8A 2.1A
CURRENT LIMIT
(2)
26.2A min 21.0A min 8.92A min 7.35A min 6.82A min 3.99A min 2.2A min
OUTPUT POWER (MAX.)
(3)
68W 100W 99.6W 99W 100.8W 98W 96W
EFFICIENCY (typ.)
100 Va-c 74% 77% 80% 80% 81% 81% 83%
240 Va-c 77% 82% 84% 84% 85% 85% 86%
RIPPLE AND NOISE
(5)
(mV p-p)
0-40°C, 10-100%
LOAD
switching (max) 80 80 100 100 100 100 130
spike noise (max)
(d-c—50MHz)
<120 <120 <150 <150 <150 <150 <200
(1) Derates same as Output Power.
(2) Current Limit is rectangular. After the overload is removed,
output is automatically restored.
(3) See power derating curve, Figure 4.
(4) Peak current and thermal protection; applicable to 24V model only.
See Figure 1 for peak power requirements.
(5) Ripple and noise will be approximately 1.5 times higher when
operating temperature range is between –10°C to 0°C.
