TABLE 3. POWER SUPPLY RATINGS AND SPECIFICATIONS
CHARACTERISTIC SPECIFICATION CONDITION/NOTES
Input Voltage Nominal: 100-120V a-c, 200-240V a-c
Range: 85-265V a-c, 120-330V d-c 0 to 100% load, -10 to 50°C
CAUTION: Input voltage exceeding
specifications may damage the unit.
Input Source Frequency Nominal: 50-60 Hz
Range: 47-63 Hz
0 to 100% load, -10 to 50°C
Input Current: (Maximum Load At
25°C with Nominal Output Voltage) 4.2A rms max. 100 - 120V a-c
2.1A rms max. 200 - 240V a-c
Switching Frequency 200KHz typ. Forward Converter
Input Protection Two thermistors reduce start-up surge. The internal power supply is protected against shorts
by an input fuse. Fuse value 10.0A at 250 Volts
Input Surge cold start, interval > 30
sec ( First surge only, not including
current flow into EMI filter)
15A typ., 20A max. first surge 100 - 120V ac
30A typ., 40 max. first surge
200- 240 V ac
Leakage Current: 0.75mA max. 240V a-c, 60Hz per IEC 60950 and UL60950
Power Factor Meets EN 61000-3-2 Rated output, rated input
Transient Recovery excursion
characteristic
±4% maximum
50% to 100% load,
transient time >50
µ
sec
recovery time 1 ms maximum
Stabilization
Source Effect (min - max) ±0.1% Typical, ±0.2% Maximum 85 to 132V a-c, 170 to 265V a-c
Load Effect ±0.6% Typical, ±1% Maximum (default)
±0.6% Typical, ±1% Maximum (see PAR. 5.)
Individual Mode: 0%-100% load change
Current Sharing: 10%-100% load change
Temperature Effect ±0.5% Typical, ±1.0% Maximum –10° to 50°C
Combined Effect ±1.2% Typical, ±2.2% Maximum Source, Load and Temperature
Time Effect 0.2% Typical, 0.5% Maximum 1/2 to 8 hours at 25°C
Start-up Time 525 msec Typical, 900 msec Maximum 100V a-c
275 msec Typical, 550 msec Maximum 240V a-c
Output Hold-up Time 20 msec Typical (28V model: 15 msec Typical)
Overvoltage Protection When the Power Supply goes into an overvoltage condition, the output is cut OFF. See PAR.
3.6.1.
Remote Control ON/OFF: ±RC pins control on/off as follows:
“High”, 2.4V to 12V (or open), unit OFF- Fan
Off;
“Low”, 0.0V to 0.8V (or shorted), unit ON.
Source current: 1.6mA maximum at low level
Sink current: 3.5 mA maximum at high level. Must be enabled by DIP switch positions 3
and 4 (see PAR. 3.5).
Meter (AM Models only) (displays
voltage or current; front panel
switch-selectable) Voltmeter Accuracy: ±3%
Ammeter Accuracy: ±5% for loads between
10%-100% Voltmeter reads sense lines; use remote
sensing to display voltage at load.
Ammeter accuracy degrades significantly for
loads less than 10%
Operating Temperature: -10 to 50°C (see Figure 2.)
Startup Temperature -20 to -10°C (see Figure 2.)
Storage Temperature: -30°C to +85°C
Withstanding voltage : (at 15-35°C
ambient, 10-85% relative humidity) 2500Va-c for 1 minute. Cutout current is 20mA Between input and ground
500Va-c for 1 minute. Cutout current is 100mA Between output and ground
3000Va-c for 1 minute. Cutout current is 20mA Between input and output terminal
