IMPORTANT NOTES:
1)
This manual is valid for the following Model and associated serial numbers:
MODEL
SERIAL NO.
REV. NO.
2)
A Change Page may be included at the end of the manual. All applicable changes and
revision number changes are documented with reference to the equipment serial num-
bers. Before using this Instruction Manual, check your equipment serial number to identify
your model. If in doubt, contact your nearest Kepco Representative, or the Kepco Docu-
mentation Office in New York, (718) 461-7000, requesting the correct revision for your par-
ticular model and serial number.
3)
The contents of this manual are protected by copyright. Reproduction of any part can be
made only with the specific written permission of Kepco, Inc.
Data subject to change without notice.
KEPCO
®
THE POWER SUPPLIER™
MODEL
OPERATOR’S MANUAL
KEPCO INC.
KEPCO, INC. ! 131-38 SANFORD AVENUE ! FLUSHING, NY. 11355 U.S.A. ! TEL (718) 461-7000 ! FAX (718) 767-1102
email: [email protected] ! World Wide Web: http://www.kepcopower.com
An ISO 9001 Company.
HSF A, AM 300W
©2013, KEPCO, INC
P/N 243-1345-r3
HSF A, AM 300 WATTS
POWER SUPPLY
HSF A, AM 300 WATTS
POWER SUPPLY
SINGLE OUTPUT POWER SUPPLIES
SINGLE PHASE, POWER FACTOR CORRECTED
UNIVERSAL AC INPUT
HSF 5-60A, HSF 12-27A, HSF 15-22A,
HSF 24-14A, HSF 28-12A, HSF 48-7A
HSF 5-60AM, HSF 12-27AM, HSF 15-22AM,
HSF 24-14AM, HSF 28-12AM, HSF 48-7AM
Document Outline
- 1. Introduction
- 2. Specifications
- 3. Features
- 3.1 DIP Switch Configuration
- TABLE 4. DIP Switch 1 and 2 Functions
- FIGURE 4. DIP Switch Configuration
- 3.2 Front Panel Access.
- 3.3 Keying
- 3.4 Output Voltage Control
- 3.4.1 Front Panel Voltage Control
- FIGURE 5. Front Panel Controls, Indicators and Test Points (HSF AM, Typical)
- 3.4.2 Remote Output Voltage Control
- FIGURE 6. DIP Switch Settings for Control of Output Voltage
- TABLE 5. Minimum Conditions for Relay, Meter and LED Operation
- FIGURE 7. Connections For Remote Voltage Control
- 3.5 Remote On-Off
- FIGURE 8. DIP Switch Settings for Using RESET button or Remote ON-OFF
- 3.6 Protection Circuits
- 3.6.1 Overvoltage And Overtemperature Protection
- 3.6.2 Overcurrent Setting and Protection
- 3.6.3 Fan Failure
- 3.6.4 Undervoltage
- 3.7 Alarm Settings
- 3.7.1 Visual Alarm.
- FIGURE 9. DIP Switch Settings for Red Alarm Indicator Enable/Disable
- 3.7.2 Alarm Signals.
- 3.7.2.1 Internal Isolated Relay Alarm
- 3.7.2.2 Optically-Coupled Logical Alarm
- FIGURE 10. DIP switch settings for Optically Coupled Logical Alarm
- FIGURE 11. Output Alarm Circuit Optically Isolated
- FIGURE 12. ±PF Power Failure Optocoupler Timing Diagram
- 3.8 Local/remote Sensing
- 3.9 Retaining Latches
- 4. Load Connection
- 5. Connecting Multiple Power Supplies
