Ballast Monitor I.M.
Ballast Monitor Instruction Manual Rev. 0.0 Page 5 of 8
5. Spare Parts
Part#
Description
348-900000-000 0-1 Lpm Rotameter with Valve
350-02QDSW-024 24VDC Solenoid 2 Position Valve
350-601403-005 0-5 Lpm Rotameter with Valve
351-900000-024 Pump, Dual Diaphragm, 120VAC
360-205420-024 24VDC 40Watt power supply
500-005151-002 Flow fault circuit assembly
823-600000-000 Genie Membrane Moisture Filter
975-041400-000 Model RL-4 Addressable Relay Module
976-041400-000 Model DA-4 Four Channel Input Module
6. Specifications
6.1 Sample Draw
Electrical Classification
NEMA 7 Explosion Proof
Dimensions 26"W x 23"H x 10"D
Power Input 120VAC @ <2Amp
Operating Temperature Range -40°C to +50°C; -40°F to +122°F
Warranty One
year
6.2 Sensor Assembly
Refer to the associated Sensor Manual.
7. Warranty
Detcon Inc., as manufacturer, warrants under intended normal use each new Model 971-071170-0DL Sample
Draw to be free from defects in material and workmanship for a period of one year from the date of shipment
to the original purchaser. Sensor assembly warranties are explained in their respective instruction manuals.
All warranties and service policies are FOB the Detcon Inc. facility located in The Woodlands, Texas.
