SW-V1-DV2 Instruction Manual Rev. 0.0 Page 7 of 7
4.0 Parts List
Detcon Part # Description
354-1916x6-024 24VDC Strobe, Ext Ground (x represents color of lamp)
Strobe colors: Red (2), Amber (4), Green (5), Blue (6), Magenta (7), and Clear (9)
500-005146-100 24V Wireless Alarm Interconnect PCA
976-000300-316 RXT-300 Wireless Transceiver
976-000320-316 RXT-320 Wireless Transceiver
976-0BP303-012 12VDC, 2200mAh Battery Pack
976-0BP303-290 12VDC, 2900mAh Battery Pack
5.0 Specifications
Strobe
Dome Colors Amber / Blue / Clear / Green / Magenta / Red
Flash Rate/Minute 60
Lamp Source LED
Alarm Unit
Operating Current 1A Max
Operating Temperature -20ºC to 60ºC
Voltage 12VDC
Dimensions 24”H X 8.2”W X 9.9”D V1 – Strobe Units
6.0 Warranty
Detcon Inc., as manufacturer, warrants under intended normal use each new SW-AV1-DV2, SW-A1-DV2, and
SW-V1-DV2 Alarm station to be free from defects in material and workmanship for a period of one year. The
warranty period begins from the date of shipment to the original purchaser and ends one year thereafter. All
warranties and service policies are FOB the Detcon Inc. facility located in The Woodlands, Texas.
7.0 Revision Log
Revision Date Changes made Approval
0.0 12/31/13 Initial Release LU
Shipping Address: 4055 Technology Forest, Suite 100, The Woodlands, Texas 77381
Mailing Address: P.O. Box 8067, The Woodlands Texas 77387-8067
Phone: 888.367.4286, 281.367.4100 • Fax: 281.292.2860 • www.detcon.com • [email protected]
