SW-AV2-DV1 Instruction Manual Rev.0.0 Page 4 of 8
When first powered on and with no battery packs connected to the charger, all the LED indicators on the Quad
Charger should be green. When a battery pack is seated into a charging port, the “CHARGE” LED will go
from green to red indicating the battery pack is not sufficiently charged. Once fully charged, the LED will go
from red to green and the battery pack is ready to be used.
The “Fault” LED should remain green indicating that there are no problems with the battery pack or charging
port. If the “Fault” LED turns red with the battery pack connected, then there is a problem or issue with the
battery pack and it should not be used and be removed immediately. If the “Fault” LED turns red without a
battery pack connected to the charge port, then there is a problem or issue with the port and that port should no
longer be used.
Battery packs can remain connected to the charger even after a full charge indication (Green “Charge” LED) is
shown due to the protection circuitry of the batter pack which prevents any overcharging issues.
1.4 RXT Series Wireless Transceivers
The wireless function of the alarm station is made possible by Detcon’s RXT series wireless
transceivers. These transceivers transmit signal data such as analog 4-20mA DC or serial Modbus™ and can
support up to 32 devices. They operate at 2.4GHz and conform to non-licensed radio frequency appliance
usage around the world. Wireless network integrity and security is accomplished using direct sequence spread
spectrum wireless mesh technology. Wireless applications can be as simple as a single field device
communicating with a host controller or any number of field devices forming a network of subscribers. Every
device in the network is capable of functioning as a router and repeater for all other devices in the
network. This means that subscribers can “hop” through neighboring devices to communicate with each other
thereby widening network access points. This unique and innovative technology is designed to create a robust
network that automatically routes around congestion and line-of-sight obstacles while improving throughput as
subscriber device density increases.
Detcon offers two models of the wireless transceiver, Model RXT-300 and Model RXT-320. Both models are
functionally similar with one major difference: the RXT-300 provides a network wide control processing
capability, whereas the RXT-320 does not. Refer to each models instruction manual for more detailed
information.
