SW-AV2-DV1
SW-AV2-DV1 Instruction Manual Rev. 0.0 Page 7 of 8
Sound Signal Frequency Repetition
Rate
Switches
SW1, SW2
Special Applications
13 Continuous note 2300 - 1 1 0 0 1
14 Continuous note 440 - 0 1 0 0 1
15 Interrupted tone 1000 2.0 1 0 0 0 1
16 Interrupted tone 420 1.25 0 0 0 0 1
17 Interrupted tone 1000 0.5 1 1 1 1 0
18 Interrupted tone 2500 0.25 0 1 1 1 0
19 Interrupted tone 2500 0.5 1 0 1 1 0
20 Interrupted tone 700 6/12 0 0 1 1 0 Pre-vital Message, SWEDEN
21 Interrupted tone 1000 1.0 1 1 0 1 0
22 Interrupted tone 700 4.0 0 1 0 1 0 Air-raid Alarm, SWEDEN
23 Interrupted tone 700 0.25 1 0 0 1 0 Local Warning, SWEDEN
24 Interrupted tone 720 0.7/0.3 0 0 0 1 0 Industrial Alarm, GERMANY
25 Int,fast,rising volume 1400 0.25 1 1 1 0 0
26 Fast siren 250-1200 0.085 0 1 1 0 0
27 Rising constant,fall 1000 10/40/10 1 0 1 0 0 Industrial Alarm, GERMANY
28 ISO 8201 Evacuation 800-1000 as std 0 0 1 0 0 International Evacuation Alarm
29 Fast whoop 500-1000 0.15 1 1 0 0 0
30 Slow whoop 500-1200 4.5 0 1 0 0 0 Evacuation Alarm, Netherlands
31 Reverse sweep 1200-500 1 1 0 0 0 0 Evacuation Alarm, GERMANY
32 Siren 500-1200 3.0 0 0 0 0 0
4.0 Parts List
Detcon Part # Description
354-FL66x4-024 Strobe alarm only (where x = 2-Red, 4-Amber, 5-Green, 6-Blue, 9-Clear)
355-YL66x4-024 Combo Strobe Horn (where x = 2-Red, 4-Amber, 5-Green, 6-Blue, 9-Clear)
356-YA6624-024 Horn alarm only
500-005146-000 24V Wireless Alarm Interconnect PCA
976-000300-000 RXT-300 Wireless Transceiver
976-000320-000 RXT-320 Wireless Transceiver
976-0BP303-290 12VDC, 2900mAh Battery Pack
