MicroFlow
™
Gear Meter Spare Parts Reference Guide
Part - Qty. per meter
[Drawing Ref. #]
JVS-01UF-25-NPT JVS-01UF-25-NPT-EX
Locating Pin - 2
[5]
Shaft - 2
[3]
Gear Assembly - 2
[4]
PTFE O-Ring - 1
[6]
FKM O-Ring - 1
[6]
Bolts - 10
[1]
Table Format:
AG15030
LP-CG Locating Pin
AW Part #
AW Part Descritption
AG15030
LP-CG Locating Pin
AG12015
ST-12KG Shaft
AG15060
SC-M6x1-30mm - 10pcs
BG10013
GR-01UF
AG15040
COT-15CG
AG15045
COV-15CG
