Dismantling & Assembly Instructions
Disconnect tool from air supply.
Remove air hose assembly (11). Take off O-ring (15). Grip body (1) and
unscrew nose (2) together with needle guide (6). Do not remove bush
(6) from nose (2). Take out spring (9), stylus (14) as fitted and O-ring (7).
Grip body (1) and unscrew ring nut (4) and unscrew throttle valve (3).
Remove valve seat (5) and seal (8).
Disconnect the air line and pour into the intake bushing a teaspoonful
(5ml) of a suitable pneumatic motor lubricating oil preferably
incorporating a rust inhibitor. Reconnect tool to air supply and run tool
slowly for a few seconds to allow air to circulate the oil. If tool is used
frequently lubricate on daily basis and if tool starts to slow or lose power.
It is recommended that the air pressure at the tool whilst the tool is
running is 90 p.s.i./6.3 bar. The tool can run at lower and higher
pressures with the maximum permitted working air pressure of 100
p.s.i./7.0 bar.
Page No 2
Safety Rules For An Engraving Pen
1) Read all the instructions before using this tool. All operators must be
fully trained in its use and aware of these safety rules.
2) Do not exceed the maximum working air pressure.
3) Use personal safety equipment.
4) Use only compressed air at the recommended conditions.
5) If the tool appears to malfunction remove from use immediately and
arrange for service and repair.
6) If the tool is used with a balancer or other support device ensure that it
is fixed securely.
7) Always keep hands away from the working attachment fitted to the tool.
8) The tool is not electrically insulated. Never use the tool if there is any
chance of it coming into contact with live electricity.
9) Always when using the tool adopt a firm footing and/or position and
grip the tool firmly to be able to counteract any forces or reaction forces
that may be generated whilst using the tool.
10) Use only correct spare parts. Do not improvise or make temporary
repairs.
11) Do not lock, tape, wire, etc. the on/off valve in the run position. The
trigger/lever etc. must always be free to return to the 'off' position when it
is released.
12) Always shut off the air supply to the tool, and depress the trigger/lever
etc. to exhaust air from the feed hose before fitting, adjusting or removing
the working attachment.
13) Check hose and fittings regularly for wear. Replace if necessary. Do
not carry the tool by its hose and ensure the hand is remote from the
on/off control when carrying the tool with the air supply connected.
14) Take care against entanglement of moving parts of the tool with
clothing, ties, hair, cleaning rags, etc. This will cause the body to be drawn
towards the tool and can be very dangerous.
15) It is expected that users will adopt safe working practices and observe
all relevant legal requirements when installing, using or maintaining the
tool.
16) Do not install the tool unless an easily accessible and easily operable
on/off valve is incorporated in the air supply.
17) Take care that the tool exhaust air does not cause a problem or blows
on another person.
Operating
Turn the valve (3) to achieve maximum power at the engraving tip. The
valve can be adjusted to reduce the impact force to work on softer
materials or to make thinner markings. If the tool fails to start tap the tip
lightly against a surface. Failure to start can occur if the valve is not open
enough. To replace or change a stylus (14) unscrew nose (2) from body
