Page 29
BAFFLE EXTENSION INSTRUCTIONS
t The
Baffle
Extension
(D6776) is intended to be used with very dry
products that free-flow with little effort. The baffle is designed to keep
these types of materials from leaking out.
t If you plan on using damp/wet materials, you should remove this
baffle by removing the self-drilling screws.
t If you are using a sand/salt mixture, remove baffle extension.
Key
Part No.
Description Qty
D 6776
Salt Baffle Extension 1
D 6869
Discharge Baffle 1
D 6874
#14 x 1-1/2" TEK w/Neo Washer 2
© Trynex International 2009 L1218
Discharge Baffle Extension Instructions
Model # SP-9300
MAX — 29
