4 D6528 1/2”-13 Serrated Hex Head Bolt
Auger Drive Assembly Parts Breakdown
Model # SP-9300
Auger Drive
Assembly
D6814 Rear Bearing Cover Plate
D6881 Rear Spinner Drive Mount
D6132 1/4”-20 x 3/4” Hex Head Bolt
D6159 10-32 x 2” HH Machine Screw
D6158 10-32 Lock Nut
D6845 Auger Bearing
D6166 5/16”-18 x 1” Hex Head Bolt
D6798 80” Auger Weldment
D6842
D6873 3/6” Keyway Stock
Transmission/Auger Coupler
D6843 Urethane Coupler Spyder
INCLUDED Coupler Set Screw
D6894 Auger Transmission
D6825 Auger Motor
D6877 #8 x 3/4” Driller With R-M Washer
D6868 Auger Motor Cover
2
2
1
1
2
2
2
1
2
2 1
1
3
1
2
1
1
6
D5706 5/16-18 Serrated Flange Nut
D6789 Auger Shaft Hopper Washer 1
D6792 Auger Shaft Hopper Collar 1
