Spreader power harness circuit diagram, Model # sp-9300 – SnowEx SP-9300 User Manual
Page 21
© Trynex International 2009 L1218
MAX— 21
Spreader Power Harness Circuit Diagram
Model # SP-9300
AUGER
Black Negative (–)
MAIN POWER PLUG
SPREADER
AUGER
Red Positive (+)
SPINNER
Red Positive (+)
SPINNER
Black Negative (–)
VIBRATOR
Black Negative (–)
VIBRATOR
Red Positive (+)
Red
Positive (+)
Black
Negative (–)
VIBRATOR
POWER PLUG
SPINNER
POWER PLUG
Black
Negative (–)
Red
Positive (+)
