Operating the Spreader

(continued)

BAFFLE INSTRUCTIONS

t The

V-Maxx

SP-9300 uses a dual baffle design over the auger area.

This baffle (D6889) is used for dry bulk materials. The baffle is

designed to reduce the risk of leakage with clean/dry free-flowing

materials. If the material you are using is damp/wet, you may need

to remove baffle (D6889). This will allow for more un-restricted flow

of materials and possible bridging.

t WARNING: Always disconnect power source before attempting to

remove material baffle.

t The main baffle assembly (D6889) must NEVER be removed from

its original factory installed position unless the unit is being serviced

or installing Optiflow Kit.

D6889
