Operating the Spreader
SP-2400 INTERIOR BAFFLE and INVERTED-V INSTRUCTIONS
• The SP-2400 uses a multi-function baffle system over the auger area.
.
This twin baffle design is used to reduce load on the auger drive train which controls amperage load to the electrical
system. It must not be removed unless servicing the unit.
• WARNING: Always disconnect power source before attempting to remove material baffle.
• There are two covers provided, one long and one short. They can be removed in different combinations depending on the
material type or moisture content. Ultimately they aid in controlling material flow to the auger area; however for wet sand
both baffles should be removed.
.
The baffle system is also connected to the vibrator link arm assembly to assist with material flow. Make sure vibrator
bolts and link arm hardware are tight before operating spreader.
Short Baffle
Long Baffle
Connect To Link Arm
Model # SP-2400
