Page 17
© Trynex International 2009 L1186
8 — 17
Frame Assembly Parts Breakdown
Model # SP-2400
Qty.
.
o
N
t
r
a
P
y
e
K
Description
2 ea.
Frame
Assembly
D 5705
D 5736
D 5728/29
D 4122
D 5730/31/32
2400 Frame Weldment
Upper Pin Bracket 1.125 & 1.0
3/8-16 x 1-1/2 HHCS
Lower Pin 1.25, 1.0, .750
1
Upper Gussett
2
2 ea.
8
1
D 5735
D 5734
Right Hand Main Bracket
Left Hand Main Bracket
1
