Auger Drive Assembly Parts Breakdown
Model # SP-2400
Auger Drive
Assembly
D6584 3/8” Flange Nut
D5527 1” Bearing
D5702 Bearing Cover
D5709 6” Variable Pitch Auger
D5706 5/16” Serrated Flange Nut
D6452 3/8” Serrated HHCS
D6842 Love Joy Coupling
D6843 Urethane Spyder
D6873 3/16” Key Stock
D6825 12 Volt Auger Motor
D6894 Auger Transmission 1
1
2
4
4
4
2
1
3
1
1
D6792 Auger Shaft Hopper Collar 1
D6789 Auger Shaft Hopper Washer 1
