© Trynex International 2009 L1186 8 — 19
.y t Q . o N t r a P y e K
1
Electrical System Parts Breakdown
Model # SP-2400
D 5716
D 6837
D 6836
D 5708
Description
Spreader Speed Control
Control Power Harness
Vehicle Harness
Spreader Harness
1
1
1
D 6839 6 Ga. Breaker wire 1
D 6851 100 Amp Resetable Breaker 1
IMPORTANT: Do not modify harness length. Any
modifications will void warranty.
IMPORTANT: In the off season remove control
and put in a cool dry place. The interior summer
temperatures could damage circuit board and
void warranty.
Anderson Block
D 6170 Anderson Connector With Leads 1
D 6841 Vehicle Harness Dust Cap 1
