Residential Gateway-I - Getting Started Guide 2-3
Connect & Power Up - Connect Cables
Figure 2-2 Connect Power Adapter
3. Connect the cable for internet access:
■ For Wireless Internet Access via Telephone Line (page 1-8), plug
the telephone cable to the correspondent socket (as shown in
Figure 2-3) and to the telephone outlet.
Depending on local standards, you may need a special adapter plug
to connect the cable to the outlet.
■ For Wireless Internet Access via External Devices (page 1-9), plug
in the UTP/Ethernet cable into the ethernet socket.
