Seed Hawk
®
Manual Calibration Guide
8
3.0 Calibration
3.1 Pre- Calibration
NOTE: Wing down pressure circuit must be active to
operate hydraulic drive motors and meter gates (if
equipped).
If operating an SCT® equipped machine, ensure meter gates
are fully open for proper product flow.
NOTE: All Meters on aircart must be individually calibrated.
Calibrations must be done each time a crop is changed.
Measure and record the weight of the empty calibration bucket.
Calibration Bucket Weight:
____________________
Remove the plate on the
bottom of the meter and place
the calibration bucket under
the meter as shown.
Turn the diverter valve to the
lower air stream position for
calibration (Return to proper
position after calibration is
complete).
