SANDPIPER M30 Metallic - Manual (Page 5)

m30mdl1sm-rev0713 Model M30 Metallic Page 3
Performance Curve, M30 Metallic Design Level 1
CAPACITY
Liters per minute
BAR PSI
HEAD
100
20(34) 40(68)
60(102)
80(136)
100(170)
80
60
40
20
0 0
1
2
3
4
5
6
7
0 20 40 60 80 100 120 140 160 180 200
900 800 700 600 500 400 300 200 100 0
220 240
U.S. Gallons per minute
120(204)
140(238)
100 PSI (6.8 Bar)
80 PSI (5.44 Bar)
60 PSI (4.08 Bar)
20 PSI (1.36 Bar)
Air Inlet Pressure
40 PSI (2.72 Bar)
30
20
25
10
15
5
9.1
6
7.6
3
4.5
1.5
NPSHR
METERS FEET
MODEL S30 Metallic Performance Curve
Performance based on the following: elastomer fitted pump, flooded suction, water at ambient conditions.
The use of other materials and varying hydraulic conditions may result in deviations in excess of 5%.
