AIR DISTRIBUTIoN VALVE

WITH STROKE INDICATOR OPTION

SERVICING

To service the air valve first shut

off the compressed air supply, bleed

the pressure from the pump, and

disconnect the air supply line from the

pump.

Step #1: See COMPOSITE REPAIR

PARTS DRAWING.

Using a 5/16" Allen wrench, remove

the four hex socket capscrews (item 12)

and four flat washers (item 38). Remove

the air valve assembly from the pump.

Remove and inspect gasket (item

18) for cracks or damage. Replace

gasket if needed.

Step #2: Disassembly of the air

valve.

To access the internal air valve

components first remove the two

retaining rings (item 1-H) from each

end of the air valve assembly using clip

ring pliers.

Next remove the two end caps (item

1-E). Inspect the o-ring (items 1-G)

and 1-M) for cuts or wear. Replace the

o-rings if necessary.

Remove the two bumpers (item

1-C). Inspect the bumpers for cut, wear

or abrasion. Replace if necessary.

Remove the spool (part of item

1-A) from the sleeve. Be careful not to

scratch or damage the outer diameter

of the spool. Wipe spool with a soft cloth

and inspect for scratches or wear.

Inspect the inner diameter of the

sleeve (part of item 1-A) for dirt,

scratches, or other contaminants.

Remove the sleeve if needed and

replace with a new sleeve and spool set

(item 1-A).

Step #3: Re-assembly of the air

valve.

Install one bumper (item 1-C) and

one end cap (item 1-E) with o-rings

(item 1-G and 1-M) into one end of the

air valve body (item 1-B). Install one

retaining ring (item 1-H), into the groove

on the same end. Insert the safety

clip (item 1-K) through the smaller

unthreaded hole in the endcap.

Remove the new sleeve and spool

set (item 1-A) from the plastic bag.

Carefully remove the spool from the

sleeve. Install the six o-rings (item 1-G)

into the six grooves on the sleeve. Apply

a light coating of grease to the o-rings

before installing the sleeve into the

valve body (item 1-B). Align the slots

in the sleeve with the slots in the valve

body. Insert the spool into the sleeve.

Be careful not to scratch or damage the

spool during installation. Push the spool

in until the pin touches the safety clip

on the opposite end.

Install the remaining bumper, end

cap with o-rings and retaining ring.

Fasten the air valve assembly (item

1) and gasket (item 18) to the pump.

Connect the compressed air line to

the pump. Remove the safety clip. The

pump is now ready for operation.

Read these instructions

completely, before

installation and start-up.

It is the responsibility of

the purchaser to retain

this manual for reference. Failure to

comply with the recommendations stated

in this manual will damage the pump, and

void factory warranty.

IMPORTANT
