Rhino Shelter BARN-12W X 28L X 12H - Manual (Page 2)

Assembly Instructions Barn Style 12 x 28 x 12
7 12 Center Straight Uprights
8 4 End Upright With Foot
9 4 Corner Wind Brace
10 16 1-1/8” End Plug
11 4 2-3/8” End Plug
12 4 Round Metal Peg
13 56 3/8"x4" Carriage Bolt
14 32 3/8"x2-7/8" Carriage Bolt
15 80 3/8” Curve Washer
16 8 3/8” Washer
17 88 3/8” Locknut
18 2 Doors Ends – Barn Style
19 12 Earth Cable Anchors
20 12 U Bolts with Nuts – 2 ½”
21 1 36” Drive Rod
22 1 Main Cover
23 1 Roll Up Door Kit w/ Hardware
Note: All Side and Base Cross Rails MUST be located on
the Inside of Arch Frame Members. Top Ridge Cross
Rails MUST be on Outside of Arch Frame members,
except at Ends. See Frame Assembly Step 5.
Plain end of Tapered Cross Rail should fasten
under the end Top Crest arch and the Tapered End
above middle Top Crest arch
V1.2
Do NOT Return Assembly To Dealer or Store. For All Assembly Questions or Shortages Please Call MDM Products Directly
Customer Service 800-447-7079 or 203-877-7070
