M360 Manual Installation & Operation 13
3 Installation & Operation
3.1 Installation
Install the blackbody emitter in the desired location that preferably has no moving air near the
emitter aperture. The M360 has been factory wired to operate from your standard 100 to
120VAC (230VAC optional) at 10 (5) amps and requires approximately 1000 watts upon power
up. Optional voltages are available upon order. Check the specification label in the rear prior to
applying power.
3.2 Operation
3.2.1 Starting Up
1. Allow the M360 to warm-up to room temperature for at least two hours after
unpacking and prior to applying power to remove any condensation.
2. Connect the power cable to a VAC service that matches the power requirement
specification noted in the Technical Data section and on the Specification Label
located on the rear of the M360.
3. Power the M360 by turning on the power switch.
Warning: Do not connect or disconnect while power is on. Do not attempt to operate
without cables connected.
Front Panel Push Buttons
PAGE Engages access to controller parameters. Do not alter any
configurations.
SCROLL Engages access to menu items underneath the Page menu.
No need to use this button.
UP/DWN Used to raise and lower the temperature setpoint.
3.2.2 Changing the Setpoint
Press the UP/DWN buttons as required to raise or lower the temperature
setpoint. To change the setpoint faster, hold the UP or DWN button in.
