IGA 320/23-LO Operating Manual

Technical data 38

Protection class:

IP 54 (IEC 60529)

Installation:

Any

Ambient temperature:

0 to 70 °C on housing, up to 200 °C on side of fiber and optical head

Storage temperature:

-20 to 70 °C

Rel. humidity:

Non condensing conditions

Weight:

0.53 kg incl. optical fiber and lens assembly

Housing:

Stainless steel

Connector:

8 pin connector

Sighting:

Built-in LED targeting light (default: continuously on)

CE-label:

According to EN 61326-1:2006-10

Note: The calibration / adjustment of the instruments was carried out in accordance

with VDI/VDE directive “Temperature measurement in industry, Radiation
thermometry, Calibration of radiation thermometers”, VDI/VDE 3511, Part 4.4.
The directive can be ordered from: “Beuth Verlag GmbH” in D-10772 Berlin, Germany.
