Digital Video Recorder User Manual
75
CHAPTER 6 Remote Surveillance
6.1 Accessing DVR
If making remote view, the DVR must connect with LAN or internet. Then enable network server in the unit. Please refer
to 4.2.7 Network Configuration.
This unit supports IE browser, not any client software installed. In addition, it supports XP and Vista.
6.1.1 On LAN
STEP1
Input IP address, Subnet, Gateway. If using DHCP, please enable DHCP in both the DVR and router.
STEP2
Enter Video to set network video parameters like resolution, frame rate etc.
STEP3
Open IE browser on a computer on the same LAN. Input the IP address of the DVR in IE address blank and
enter.
STEP4
IE will download activeX automatically. Then a window pops up and asks for user name and password.
STEP5
Input name and password correctly, and enter. It will show the picture as below.
