Digital Video Recorder User Manual
5
STEP3 Fix the HDD firmly by screws, and then connect with data cables.
In addition, users can put hard-disk drive into the HDD box shown as Fig. 2.2 if they do not need install DVD writer.
Fig. 2.2 Hard-disk Drive Box
2.1.2 Install DVD Writer
Notice: 1. The writers must be the compatible devices we recommend. Please refer to “Appendix C Compatible Devices”
2. This device is only for backup
STEP1 Unscrew and Open the top cover
STEP2 Connect with the power and data cables. Put DVD Writer into the position of CDROM. Usually, if it is required to
attach DVD Writer when ordering, the manufacturer will install it well at leaving factory.
Notice
:
If some users do not need install DVD Writer, they can install hard-disk drive here as said the above.
2.2 Front Panel Instructions
The Front Panel interface is shown as Fig 2.3 Front .
