9 Power Shot switch off
10 Indicators Working indicators of HDD
11 INFO Check basic setup parameters of record
12 AUTO/－ Change screens automatically/Decrease the value in setup
13 P.T.Z. Enter PTZ mode in live
14 BACKUP Enter backup mode in live
15 MENU Enter menu in live
16 REC Record manually
17 SEARCH Enter search mode
18 PLAY Enter playback interface
19 REW Rewind
20 FF Fast forward
21 STOP Quit playback mode
22 IR receiver For remote controller
23 USB port To connect external USB devices like USB flash, USB HDD for backup or update firmware
Tab 2.1 Definition of Front Panel Buttons
2.3 Rear Panel Instructions
2.3.1 Rear Panel Interface
The rear Panel interface is shown as Fig 2.5 Rear .
