VANTAGE 300
1. Output rating in watts is equivalent to volt-amperes at unity power factor. Output voltage is within ± 10% at all loads up to rated capacity.
When welding, available auxiliary power will be reduced.
* Engine warranty may vary outside of the USA. (See Engine warranty for details).
** To Top of enclosure, add 7.88”(200.2mm) to top of exhaust pipe. Add 4.012”(101.9mm) to top of Lift Bail.
A-1 INSTALLATION A-1
TECHNICAL SPECIFICATIONS - VANTAGE 300 (K2409-1, K2499-1)
INPUT - DIESEL ENGINE
RATED OUTPUT @ 104° F (40° C) - WELDER
HEIGHT WIDTH DEPTH WEIGHT
35.94** in. 25.30 in 60.00 in. 1035 lbs. (469kg.) Kubota
913 mm 643 mm 1524 mm 1150 lbs. (522kg.) Deutz
LUBRICATION EMISSIONS FUEL SYSTEM GOVERNOR
Full Pressure Mechanical Fuel Pump, Auto air bleed Mechanical Kubota
with Full Flow Filter EPA Tier Il Ready system Electric shutoff solenoid Indirect fuel injector. Electronic Deutz
AIR CLEANER ENGINE IDLER MUFFLER ENGINE PROTECTION
Low noise Muffler: Shutdown on low oil
Single Element Automatic Idler Top outlet can be rotated. pressure & high engine
Made from long life, aluminized steel. coolant temperature
ENGINE WARRANTY: 2 year complete (parts and labor) 3rd. year major components (parts and labor)
Welding Process
DC Constant Current
DC Pipe Current
Touch-Start™TIG
DC Constant Voltage
Output Range
20 TO 400 AMPS
40 TO 300 AMPS
20 TO 250 AMPS
14 TO 32 VOLTS
Max. Weld OCV
@Rated Load RPM
60 Volts
Welding Output
Current/Voltage/Duty Cycle
300A / 32V / 100%
350A / 28V / 100%
300A / 32V / 100%
250A / 30V / 100%
300A / 32V / 100%
350A / 28V / 100%
Auxiliary Power 1
11,500 Watts Peak, / 10,000 Watts Continuous, 60 Hz 120/240 Volts Single Phase
12,500 Watts Peak, /11,000 Watts Continuous, 60 Hz, 240 Volts 3-Phase
PHYSICAL DIMENSIONS
ENGINE
RATED OUTPUT @ 104° F (40° C) . - GENERATOR
Make/Model
K2409-1
Kubota*
V1505
K2499-1
Deutz*
D2008 L4
Description
4 Cylinder
naturally
aspirated
Water Cooled
Diesel Engine
Horsepower
@ 1800 RPM
22 HP
24 HP
Operating
Speed (RPM)
High
1890 RPM
Full Load
1800 RPM
Low Idle
1350 RPM
High
1800 RPM
Full Load
1800 RPM
Low Idle
1400 RPM
Displacement cu. in. (ltrs.)
Bore x Stroke inch (mm)
91.41(1.5)
3.07 x 3.09 (78 x 78)
95 (1.56)
3.0 x 3.4 (76 x 86)
Starting
Systems
12VDC Battery
and starter
(Group 34;
Battery 535 cold
crank amps)
Battery Charger
Capacities
Fuel: 15gal.(57L)
Oil: 6.4qts.(6.0L)
Radiator
Coolant:
7.2qts.(6.8L)
Fuel: 15gal.(57L)
Oil: 7.8qts.(7.4L)
Radiator
Coolant:
7.9qts. (7.5L)
