A-2
INSTALLATION
VANTAGE 300
A-2
Δ For Code 11185.
◊
For Codes above 11186
RECEPTACLES AUXILIARY POWER CIRCUIT BREAKER OTHER CIRCUIT BREAKERS
(2) 120VAC GFCI Duplex (5-20R) Two 20AMP for Two Duplex Receptacle 10AMP for Engine Battery
(1) 120/240VAC Dual Voltage (1) 50AMP for Dual Voltage (2-pole)
Δ
Charging Circuit
Full KVA (14-50R)
(1) 30Amp for 3-Phase (3-pole)
Δ
10AMP for 42V Wire Feeder Power
(1) 240VAC 3-Phase (15-50R) (1) 50Amp for Dual Voltage and 3-Phase (3-pole)◊
MACHINE SPECIFICATIONS
