Control cable “w” t orches, Length of cable required for item #4 – Lincoln Electric IM818 Prince XL 350 User Manual

Page 32

background image

Prince

®

XL - Owner's Manual - Page 25

E

LECTRICAL

C

ONTROL

C

ABLE

Control Cable

“W” T

orches

001-3784, 001-3785, 001-3787,

001-3788, 001-3789, 001-3790, 001-3800

No.

Qty

.

Part No.

Description

1

1

153-0322

Connector

, 7 Pin, “W”

2

1

301-0004

Boot

3

1

41

1-0025

Clamp

4

table

844-0070

Cable, & Cond, 22 Ga.

5

0.30ft

739-0004

T

ubing, Shrink, Ø1/8

6

1

405-0762

Label, Self Laminate

7

1

41

1-0159

Clamp, Retaining

8

1

331-0087

W

asher

, Flat, Neoprene

9

7

153-0852

Male Pins

10

1

153-0857

5 Pin Female Connector

1

1

1

153-0856

2 Pin Female Connector

Length of cable required

for item #4

25’

25.5 ft.

50’

50.5 ft.

75’

75.5 ft.
