Prince ® XL - Owner's Manual - Page 18
P
RINCE
®
XL E
XPLODED
V
IEW
MK P/N 313-725 LE P/N K2296-2
Prince
®
XL,
Air Cooled
dwg 001-1346c
No.
Qty
.
Part No.
Description
1
1
001-1
144
Lead 25ft
Air Cool 7W
2
1
003-0567
Assy Potentiometer PXL
3
1
003-0585
Assy T
rigger
PXL
4
1
003-1972
Assy Body PXL
5
1
003-1974
Clamp Leads PXL
61
LE KP2298-1 MK 003-2151
Assy Barrel Str
A/W PXL
7
7
153-0852
Pin
8
1
153-0856
Connector Molex 2 Pos
9
1
153-0857
Connector Molex 5 Pos
10
1
21
1-0071
Motor
1
1
3
328-0003
Screw Shc 4-40 x 0.50
12
4
333-0003
Wshr Spr Lk #4
13
2
333-0005
Wshr Spr Lk #6
14
2
336-0049
Screw Pnhd Ph 4-40 x 0.625 St
15
2
336-0056
Screw Pnhd Ph 4-40 x 1.50 St
16
2
336-0070
Screw Pnhd Ph 6-32 x 1.50
17
1
405-0706
Label Serial Number
18
1
41
1-0045
T
ie W
rap
19
1
421-0408
Pin Dowel Ø0.093 x 2.00 LG
20
1
421-0409
Pin Dowel Ø0.093 x 1.25 LD
21
1
431-31
17
Door PXL
22
1
435-3124
Spring Door PXL
23
1
436-0136
Handle Right SS PXL
24
1
436-0137
Handle Left SS PXL
25
1
437-0237
Spacer Handle PXL
26
1
51
1-0101
Driveroll Gold
27
1
751-0020
Cap Plug 0.218 ID x 0.50 LG
28
A/R
823-0029
Anti-Corrosion Compound
29
A/R
823-0050
Thread Locking Cmpd Low Str
30
A/R
835-0006
Lubricant Silicon
