Lincoln Electric IM667 Mobiflex 400-MS - Manual (Page 25)

Recommended Spare Parts are Highlighted in Bold
1 Fan Housing, Motor Side S23281-1 1 X
2 Fan Wheel S23281-2 1 X
3 Control Housing, Mobiflex S23281-3 1 X
4 Replacement Hose, 4 ft. S23282-12 1 X
5 Spark Arrester, 400-MS S23281-24 1 X
6 Replacement Filter, 400-MS K1673-2 1 X
7 Filter Cover, Mobiflex 400-MS S23281-26 1 X
8 Thumb Nut S23281-7 1 X
9 Cleaning Unit, 400-MS, Complete S23281-27 1 X
10 Air Valve & Solenoid (included in item 9) S23281-28 1 X
11 Housing, Mobiflex 400-MS S23281-29 1 X
12 Dust Tray S23281-30 1 X
13 Rear Wheel, Mobiflex S23281-9 2 X
15 Pressure reducing valve S23281-31 1 X
16 Front Caster Assembly, Mobiflex S23281-10 2 X
17 Motor S23281-14 1 X
19 Contactor, 24V, 60Hz S23284-5 1 X
20 Starter/ Overload Switch K1494-2 1 X
22 Transformer S23284-4 1 X
23 Indicator, 400-MS S23281-32 1 X
24 Reset/Start Button S23281-33 1 X
25 Fuse S23284-2 1 X
26 Control PC Board, 400-MS S23281-34 1 X
27 Pressure Difference switch, 400-MS S23281-35 1 X
ITEMS NOT ILLUSTRATED
Motor Capacitor
S23281-4 1 X
Rubber Seal, 8” S23282-1 1 X
4-30-99
MOBIFLEX 400-MS
Use only the parts marked “x” in the column under the
heading number called for in the model index page. # Indicates a change this printing.
P-359
π-C.1
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
P-359-C.1
