GENERAL DESCRIPTION
The MINIFLEX ® is a portable, high vacuum welding fume extractor
designed for the removal and filtration of welding fumes from light
duty welding applications. Its compact size permits the MINIFLEX to
be used in confined spaces and other locations that are not
accessible with other welding fume extractors.
The convenient automatic start/stop function can extend the life of the
motor brushes and reduces energy consumption. (Note: welding
current must be at least 50 amps to activate sensor). The optional
wall mounting bracket allows the unit to be mounted to a wall, freeing
up floor space.
The MINIFLEX can be completely disassembled in a matter of minutes
for cleaning and maintenance.
Unit includes:
• 8 ft. (2.5 m) extraction hose with 1-3/4 in. (45 mm) O.D.
hose adapter.
• Two sets of seals and carbon brushes.
USE WITH NOZZLES AND HOSES
The MINIFLEX is not supplied with a nozzle. Nozzles and extra hoses
can be ordered separately. The recommended nozzles and hoses are:
• Extraction Nozzles: EN 20 or 40 (K2389-5 and K2389-6)
• Nozzle Kits: NKT or NKC (K2389-3, K2389-4)
• Fume Exhaust Guns
• Extraction Hoses:
- 8 ft. (2.5m) long x 1-3/4 in. (45mm) O.D. (K2389-9)
- 16 ft. (5m) long x 1-3/4 in. (45 mm) O.D. (K2389-8)
• Hose-to-Hose Adapter (K2389-10)
• Hose Connection Outlet (K2389-2)
See Accessories section for more information.
Note: Recommended maximum hose length is 24 ft. (7.5 m) on extraction side
of unit. Consult Lincoln Electric Automation Department at
1.888.935.3878 before using any other size or length of hose.
TECHNICAL
SPECIFICATIONS
(1) Particle size: 0.3 μm. Testing method: Flat-sheet tested according to
EN 1822-3:2009 @ 190 m
3 /h with test aerosol generated according to
1822-2:2009.
NOTE: Technical specifications are subject to change without prior notice.
Specifications and guarantees are valid only when specified
replacement parts and filters are used.
9
INSTALLATION MINIFLEX ® PORTABLE WELDING FUME EXTRACTOR
GENERAL
INPUT VOLTAGE 115V, 1Ph, 60Hz
230V, 1Ph, 60Hz
RATED CURRENT DRAW 115V - 14.6A
230V - 8.8A
POWER RATING 2.4 HP (1.2 HP PER MOTOR)
OPERATING SOUND LEVEL < 70 DB(A)
AMBIENT CONDITIONS
MINIMUM TEMPERATURE 40ºF (5ºC)
MAXIMUM TEMPERATURE 104ºF (40ºC)
MAXIMUM RELATIVE HUMIDITY 80%
OPERATING CAPACITY
EXTRACTOR TYPE HIGH VACUUM, LOW VOLUME
AIRFLOW RATE LOW MODE: 94 CFM (160 M 3 /HR)
HIGH MODE: 135 CFM (230 M 3 /HR)
PHYSICAL DIMENSIONS
HEIGHT 29.0” (730 MM)
DIAMETER 16.5” (420 MM)
INLET/OUTLET OUTER DIAMETER 1-3/4” (45 MM)
WEIGHT 38 LBS. (17 KG)
FILTER TYPE
STAGE ONE SEPARATE MESH SCREEN
PRE-FILTER
STAGE TWO INTEGRATED MESH/SCREEN
PRE-SEPARATOR
STAGE THREE LONGLIFE-H™ PRETREATED
CELLULOSE FILTER
STAGE THREE SURFACE AREA 130 SQ. FT. (12 M 2 )
STAGE FOUR (OPTIONAL) ACTIVATED CARBON FILTER
STAGE FIVE HEPA (HIGH EFFICIENCY
PARTICULATE AIR) FILTER
UNIT EFFICIENCY UP TO 99.7% (1)
