Lincoln Electric IM857 MINIFLEX K3972-1 & K3973-1 - Manual (Page 21)

Miniflex ® Portable Fume Extractor, Includes: K2376-1 1 X • •
Miniflex ® Portable Fume Extractor, Includes: K3972-1 1 • X •
Miniflex ® Portable Fume Extractor, Includes: K3973-1 1 • • X
1 Control Panel and PC Board S23384-22 1 X • •
2 Switch S23384-23 1 X X X
3 Carbon Brushes (2 sets) 115V (includes seals) S23384-24 1 X X •
3 Carbon Brushes (2 sets) 230V (includes seals) S23384-64 1 • • X
4 Motor, 115V (includes seals) S23384-25 2 X X •
4 Motor, 230V (includes seals) S23384-65 2 • • X
5 Prefilter KP2390-3 1 X X X
6 Set of Wheels (2 pieces, excludes Wheel Covers) S23384-27 1 X X X
6B Wheel Cover, pair S23384-56 1 X X X
7 Seals, Main Filter (Set) S23384-26 1 X X X
8 LongLife-H Filter KP2390-1 1 X X X
9 Outlet Cover S23384-49 1 X X X
10 HEPA Filter KP2390-2 1 X X X
11 Handle S23384-50 1 X X X
12A Control Panel (Not Shown) S23384-66 1 • X X
12B PC Board 115V or 230V (Not Shown) S23384-67 1 • X X
13 Wheel Axle and Starlocks S23384-54 1 X X X
14 Housing Latch and Clip (Includes 2 sets) S23384-55 1 X X X
Jan-14
MINIFLEX ®
Use only the parts marked “x” in the column under the
heading number called for in the model index page. # Indicates a change this printing.
P-517-A.1
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
P-517-A.1
