VT6420 User Manual – SATA Controller
Revision 1.01, May 19, 2003
20 RAID
Software
The main interface is divided into two windows and the toolbar above contain the main functions. Click on these toolbar buttons
to execute their specific functions. The left windowpane displays the controller and disk drives and the right windowpane displays
the details of the controller or disk drives.
View by Controller
Create Mirror Array (RAID 1)
Create Span Array (JBOD)
Create Stripe Array (RAID 0)
Add/Remove Spare disk
Remove Array
View Event log
Check All Disks
View by Devices
Help Topics
