The Easy to Upgrade HDD Module
The hard drive in your notebook computer is made to be easily swapped out for upgrading. You
should back up your hard drive before attempting o change the hard drive. Make sure that before
you install a new drive, all the files in your system should be backed up.
To upgrade your Hard Drive
Power down the system completely. Turn the system over with the front of the unit facing
you.
Remove the three screws that secure the compartment cover and set them in a safe place.
Slide the HDD cover away from the compartment.
The drive is attached to a special bracket that secures it to the notebook computer. There are
4 screws hold the bracket. Remove the screws and set them in a safe place.
Push the HDD slightly in the direction of the arrow as shown in the illustration to release it
from the pins of the drive.
Gently hold the grip of the HDD, lift it up to release from its compartment.
To install the new HDD, you will need to align the tabs on the drive bracket with the slots on
the bay. Press down gently on the drive bracket until it engages with the system. Do not
force the drive into place this can bend the pins on the hard drive.
