PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Main Advanced Chipset Tweak Boot Security Exit
CPU Temperature : 55
System Temperature : 51 o C
CPU Fan Speed : 1635 RPM
System Fan Speed : 1639 RPM
CPU Voltage : 1.760V
DIMM Voltage : 1.496V
TCC Activation Temperature (DTS) 100
PC Health Status
+/- : Change Opt.
Enter/Dbl Click : Select
 : Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit

• CPU Temperature
• System Temperature
• CPU Fan Speed
• System Fan Speed
• CPU Voltage
• DIMM Voltage
System Component Characteristics
These items display the monitoring of the overall inboard hardware health events,
such as System temperature, CPU & DIMM voltage, CPU & System fan speed... etc.
Press to return to the Advanced Menu page.
