H87h3-ti user manual, Chapter 2 – Elitegroup H87H3-TI (V1.0) User Manual
Page 25
Chapter 2
21
H87H3-TI USER MANUAL
If you use AC
’
97 Front Panel, please
t
ick off the option of
“
Disabled Front Panel
Detect
”.
If you use HD Audio Front Panel, please
don
’ t t
ick off
“
Disabled Front Panel
Detect
” .
* For reference only
AC
’
97 Audio Configuration: To enable the front panel audio connector to
support AC97 Audio mode.
10. ME_UNLOCK: ME unlock header
