Z87H3-A3X USER MANUAL
Chapter 7
2. When the RAID Level item is highlighted, use the up/down arrow key to
select the RAID set that you want to create.
Creating a RAID set
1. In the main Intel ® Matrix Storage Manager RAID BIOS menu, highlight
Create RAID Volume using the up/down arrow key then press .
3. Key in the RAID volume capacity. Use the up/down arrow to choose the
Capacity. The default value indicates the maximum capacity using the
selected disks. Entering a lower capacity allows you to create a second
volume on these disks.
When more than two HDDs are installed in your computer, the Disks item
will be selectable. Then users can select the HDD that you want to belong
to the RAID set. Please be noticed that selecting a wrong disk will result in
losing the original data of the HDD.
[ Main Menu ]
1. Create RAID Volume 4. Recovery Volume Options
2. Delete RAID Volume 5. Acceleration Options
3. Reset Disks to Non-RAID 6. Exit
[ CREATE VOLUME MENU ]
Name: Volume0
RAID Level:
RAID0(Stripe)
Disks: Select Disks
Strip Size: 128KB
Capacity: 931.5 GB
Create Volume
[ CREATE VOLUME MENU ]
Name: Volume0
RAID Level:
RAID1(Mirror)
Disks: Select Disks
Strip Size: N/A
Capacity: 465.8 GB
Create Volume
[ CREATE VOLUME MENU ]
Name: Volume0
RAID Level: RAID0(Stripe)
Disks:
Select Disks
Strip Size: 128KB
Capacity: 931.5 GB
Create Volume
[ CREATE VOLUME MENU ]
Name: Volume0
RAID Level: RAID0(Stripe)
Disks:
Select Disks
Strip Size: 128KB
Capacity:
931.5 GB
Create Volume
