Z87h3-a3x user manual, Chapter 2, 4-7. connecting case components – Elitegroup Z87H3-A3X (V1.0) User Manual
Page 30
Chapter 2
24
Z87H3-A3X USER MANUAL
No.
Components
No.
Components
1
CPU_FAN 2
6
F_PANEL
2
CPU_FAN 1
7
SPK
3
ATX_POWER
8
SYS_FAN1
4
SYS_FAN3
9
PWR_FAN
5
SYS_FAN2
10
ATX12V
After you have installed the motherboard into a case, you can begin connecting the
motherboard components. Refer to the following:
2-4-7. Connecting Case Components
