Chapter 3
Z87H3-A3X USER MANUAL
35
PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Scroll to this item and press to view the following screen:
 Smart Fan Function
Main Advanced Chipset M.I.B. X Boot Security Exit
CPU Temperature (DTS) : 48
System Temperature : 27 O C
CPU Fan 1 Speed : 4017 RPM
CPU Fan 2 Speed : 0 RPM
System Fan 1 Speed : 0 RPM
System Fan 2 Speed : 0 RPM
System Fan 3 Speed : 0 RPM
Processor Input Voltage : 1.752V
DIMM Voltage : 1.512V
+12V : 12.168V
+5V : 5.120V
+3.3V : 3.360V
PCH Core Voltage : 1.044V
TCC Activation Temperature (DTS) 92
Smart Fan Function
PC Health Status
Enable CPU Fan 1 SmartFan
Main Advanced Chipset M.I.B. X Boot Security Exit
CPU Fan 1 Smart Fan Control Enabled
Smart Fan Mode Normal
Smart Fan start PWM value 180
Smart Fan start PWM TEMP (DTS)
45
DeltaT +3
Smart Fan Slope PWM value 10 PWM value / unit
CPU Fan 1 Full Speed Offset (DTS) 52
CPU Fan 2 Smart Fan Control Enabled
Smart Fan Mode Normal
Smart Fan start PWM value 180
Smart Fan start PWM TEMP (DTS)
45
DeltaT +3
Smart Fan Slope PWM value 10 PWM value/unit
CPU Fan 2 Full Speed Offset (DTS) 52
System Fan 1 Smart Fan Control Enabled
Smart Fan Mode Normal
Smart Fan start PWM value 180
Smart Fan start PWM TEMP (DTS)
45
DeltaT +3
Smart Fan Slope PWM value 10 PWM value/unit
System Fan 1 Full Speed Offset (DTS) 52
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
F9: Capture Screen
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
F9: Capture Screen
