Chapter 3
Z87H3-A3X USER MANUAL
39
CPU Configuration
The item in the menu shows the CPU.
Intel(R) Core(TM) i5-4570S CPU @ 2.90GHz
This is display-only field and displays the information of the CPU installed in your
computer.
EM64T (Supported)
This item shows the computer supports EM64T.
Processor Speed (2900MHz)
This item shows the current processor speed.
Processor Stepping (306c3)
This item shows the processor stepping version.
Microcode Revision (9)
This item shows the Microcode version.
Processor Cores (4)
This item shows the core number of the processor.
Intel HT Technology (Not Supported)
This item shows the computer not supports Intel HT Technology.
Main Advanced Chipset M.I.B. X Boot Security Exit
Number of cores to enable
in each processor package. CPU Configuration
Intel(R) Core(TM) i5-4570S CPU @ 2.90GHz
EM64T
Supported
Processor Speed 2900 MHz
Processor Stepping 306c3
Microcode Revision 9
Processor Cores 4
Intel HT Technology Not Supported
Intel VT-x Technology Supported
Active Processor Cores All
Limit CPUID Maximum Disabled
Execute Disable Bit Enabled
Intel Virtualization Technology Enabled
LakeTiny Feature Enabled
CPU C3 Report Enabled
CPU C6 Report Disabled
CPU C7 Report Disabled
Package C State limit AUTO
Enhanced Halt (C1E) Enabled
Active Processor Cores (All)
Use this item to control the number of active processor cores.
Limit CPUID Maximum (Disabled)
Use this item to enable or disable the maximum CPUID value limit, you can enables
this item to prevent the system from “rebooting” when trying to install Windows NT
4.0.
Intel VT-x Technology (Supported)
This item shows the computer supports Intel VT-x Technology.
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
F9: Capture Screen
