Chapter 2
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
fHT Control
Scroll to this item to view the following screen:
lk
:Select Screen
+/- : Value
Enter : Select
mn
:Select Item
F1:General Help
F2:Previous Value
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Main Advanced Chipset M.I.B. III Boot Security Exit
Set Upstream Link Width .
HT control
Current Width Up: 16 bit
Upstream Link Width [Auto]
Current Width Down: 16 bit
Downstream Link Width: [Auto]
Current IO HT Freq: 2200Mhz
IO HT Frequency [Auto]
Current Width Up (16 bit)
This item shows the current Upstream Link Width.
Upstream Link Width (Auto)
This item allows you to set Upstream Link Width.
Current Width Down (16 bit)
This item shows the current Downstream Link Width.
Downstream Link Width (Auto)
This item allows you to set Downstream Link Width.
Current IO HT Freq (2200Mhz)
This item shows the current IO HT Frequency.
IO HT Frequency (Auto)
This item allows you to set IO HT Frequency.
