Brocade FastIron Ethernet Switch Feature and RFC Support Matrix - Manual (Page 19)

Feature ICX 6430 ICX 6450 FCX ICX 6610 ICX 6650 FSX 800
FSX 1600 ICX 7750
MLD v1/v2 snooping (global and local) 08.0.01 08.0.01 08.0.01 08.0.01 08.0.01 08.0.01 08.0.10
MLD fast leave for v1 08.0.01 08.0.01 08.0.01 08.0.01 08.0.01 08.0.01 08.0.10
MLD tracking and fast leave for v2 08.0.01 08.0.01 08.0.01 08.0.01 08.0.01 08.0.01 08.0.10
Static MLD groups with support for proxy 08.0.01 08.0.01 08.0.01 08.0.01 08.0.01 08.0.01 08.0.10
MLD v1/v2 snooping per VLAN 08.0.01 08.0.01 08.0.01 08.0.01 08.0.01 08.0.01 08.0.10
PIM6-SM snooping 08.0.01 08.0.01 08.0.01 08.0.01 08.0.01 08.0.01 08.0.10
IPv6 Multicast
Documents software features supporting IPv6 Multicast.
The following features are documented in the FastIron Ethernet Switch IP Multicast Configuration
Guide.
Feature ICX 6430 ICX 6450 FCX ICX 6610 ICX 6650 FSX 800
FSX 1600 ICX 7750
MLD (v1 and v2) No
08.0.01
08.0.01 08.0.01 08.0.10a
08.0.01 9
08.0.10
MLD membership tracking and fast
leave for v2 No
08.0.01
08.0.01 08.0.01 08.0.10a
08.0.01 9
08.0.10
IPv6 PMRI No 08.0.01 10 08.0.01 08.0.01 08.0.10a 08.0.01 9 08.0.10
IPv6 PIM-SSM No 08.0.01 10 08.0.01 08.0.01 08.0.10a 08.0.01 9 08.0.10
IPv6 PIM Sparse No 08.0.01 10 08.0.01 08.0.01 08.0.10a 08.0.01 9 08.0.10
IPv6 PIM Anycast RP No 08.0.01 10 08.0.01 08.0.01 08.0.10a 08.0.01 9 08.0.10
IPv6 multicast boundaries No 08.0.01 10 08.0.01 08.0.01 08.0.10a 08.0.01 9 08.0.10
Embedded RPv6 No 08.0.01 10 08.0.01 08.0.01 08.0.10a 08.0.01 9 08.0.10
Multi-VRF support No 08.0.01 10 08.0.01 08.0.01 08.0.10a 08.0.01 9 08.0.10
Hardware replication resource sharing No 08.0.01 10
08.0.01 08.0.01 08.0.10a
08.0.01 9
08.0.10
Concurrent support for multicast routing
and snooping No 08.0.01 10
08.0.01 08.0.01 08.0.10a
08.0.01 9
08.0.10
Static mroute No 08.0.10a 10
08.0.10a 08.0.10a 08.0.10a
08.0.10a 9
08.0.10a
9 3rd generation modules only.
10 In a mixed stack only
IPv6 Multicast
FastIron Ethernet Switch Feature and RFC Support Matrix 19
53-1003078-04
