background image

4

On the top of each Adjustment Dial you will notice that there are arrows indicating direction of

movement.

Turning the Elevation Adjustment Dial counter-clockwise will shift the bullet point of impact

up, and turning it clockwise will shift the bullet point of impact down.

Turning the Windage Adjustment Dial counter-clockwise will shift the bullet point of impact

right, and turning it clockwise will shift the bullet point of impact left.

The Elevation and Windage Adjustment Dials also feature Audible and Tactile Clicks which not

only can you see and hear the adjustments, but you can feel them as well. Each Click moves the

reticle point of aim ¼ or ½ MOA* at 100 Yards (depending on the scope model you have). The
chart below represents the amount of movement of each click at various distances.

Elevation/Windage movement per click

Magnification 100 yards 200 yards 300 yards 400 yards 500 yards

1.1X – 4X models

½ MOA

1 MOA

1½ MOA

2 MOA

2½ MOA

3X – 9X models

¼ MOA

½ MOA

¾ MOA

1 MOA

1¼ MOA

*1 MOA = 1.047 Inches at 100 Yards

Zeroing your Scope

After you have completed the installation of your scope it will be necessary to adjust the scopes

point of aim to match the bullet’s point of impact on a target. This can be accomplished using

several methods, but we recommend the use of a Bore Sighting Device to save time and ammunition.
Using a Bore Sighting Device will ensure that your shots land “on paper”. Follow the Manufacturer’s
Instructions for the Bore Sighting Device that you choose in order to achieve the best results. You

are now ready to finalize your Zero.

CAUTION: ALWAYS BE SURE TO REMOVE THE BORE SIGHTING DEVICE BEFORE

SHOOTING LIVE AMMUNITION. FAILURE TO DO SO CAN CAUSE DAMAGE TO YOUR
FIREARM OR INJURY TO YOURSELF AND THOSE AROUND YOU.

CAUTION: WHEN OPERATING ANY TYPE OF FIREARM ALWAYS USE PROPER EYE

AND EAR PROTECTION. BE SURE TO USE YOUR FIREARM IN AN AREA THAT IS
PERMISSIBLE UNDER LOCAL, STATE, AND FEDERAL LAW.

Bore Sighting alone is not sufficient enough to ensure an accurate Zero. You must shoot your

firearm at the range in order to confirm an accurate Zero. Follow these steps to fine tune your scope

adjustments:

1. Secure your firearm using a steady platform such as a bench rest or sand bags.

2. Fire 3 to 5 carefully aimed shots at a target that is set to your desired Zeroing distance (50 or

100 yards is recommended).

3. Observe where the bullets have struck the target and make adjustments to the Elevation and

Windage settings as necessary until your point of aim matches your point of impact.

4. Continue with this process until you have achieved your desired level of accuracy.

5. Your scope is now Zeroed to your firearm at the distance that you have chosen.
