High Frequency Control Settings
Not all setups are identical and neither
are all rooms. The high frequency level
controls on the rear of each CF101LA
and CFX101LA point source array
module allow you to adjust the high
frequency output of each module to
compensate for the increased loss of
high frequency energy from air loss over
distance, for increased coupling between
array modules at low frequencies and for
varying room sizes and acoustics. They
allow you to maintain the proper High/
Mid/Low frequency balance throughout
the listening area.
The control settings shown below are provided as guide lines to assist you in setup. They are not
“hard and fast” settings that apply to every setup as no two setups are alike.
Set controls to Flat
Set all controls to + 6 dB
Set all controls to + 9 dB
Set all controls to + 9 dB
